Simultaneous HPLC Determination Of Hydrophilic Whitening Agents in Cosmetic Products
Mar 22, 2022
Contact: joanna.jia@wecistanche.com / WhatsApp: 008618081934791
Miaw-Ling Chang a , Chur-Min Chang b,*
Abstract
A high-performance liquid chromatographic method for quantifying four of the most commonly used hydrophilic whitening agent*/glycolic acid (GA), ascorbic acid (AA), arbutin (ART), and Mg ascorbyl phosphate (MAP), has been developed. Isocratic separation was performed using a C18 column with the ion-pair agent as a mobile phase. The analytes were detected by ultraviolet light absorption at the wavelength of 220 and 240 nm, respectively. Calibration curves were found to be linear in the 8.0-36 mg/ml (GA), 10.0-300 mg/ml (AA and ART), and 5.6-451 mg/ml (MAP). The correlation coefficient of linear regression analysis was with the range 0.9974-0.9997. Recoveries of the four analytes were between 94.8 and 100.1% and the precision of this method was better than 6.9% relative standard deviation (R.S.D.) (n=3). It was found that AA degraded in an aqueous solution. To be sure that AA was stable during the HPLC analysis, all analytes were dissolved in distilled water and these solutions were purged with nitrogen gas to remove oxygen and stored at 25 8C. The testing results show that the procedure is the rapid, simple, selective method and it is suitable for routine analysis of commercial cosmetics. # 2003 Elsevier B.V. All rights reserved.
Keywords: Cosmetic product; Hydrophilic whitening agent; Glycolic acid; Ascorbic acid; Arbutin; Mg ascorbyl phosphate; HPLC
Cistanche herba is a natural whitening agent.
1. Introduction
Westerners consider tanned skin healthy and beautiful. On the contrary, light skin is considered beautiful in oriental countries. Therefore, whitening lotions are very popular in the oriental. They are applied for whitening the skin. Chemical peeling is usually used in clinical treatment for damaged facial skin arising from acne, melasma, common warts, and so on. In this technique, cosmetic products containing a chemotherapeutic agent are applied to the skin for stimulating the renewal of the skin cells. The color of the skin becomes lighter. Thus this chemo-therapeutic agent is also called a whitening agent [1-6]. It has been reported that a whitening agent like glycolic acid (GA), one of the hydroxy acids, increases the hydration of the skin and, therefore, gives a smoother appearance, resulting in fewer facial lines and wrinkles [7,8]. There are two types of whitening agents: lipophilic whitening agents and hydrophilic agents. Examples of lipophilic whitening agents are kojic acid, salicylic acid, ascorbyl palmitate, azelaic acid, and adapalene. Examples of hydrophilic whitening agents are glycolic acid (GA), ascorbic acid (AA), arbutin (ART), and magnesium ascorbyl phosphate (MAP). The hydrophilic whitening agents are studied here because their polar groups have a poor affinity to the C18 column used in HPLC and it is difficult to separate them in HPLC. We used an ion-pair method to solve this problem.
The chemical structures and the maximum concentration of these hydrophilic whitening agents are given in Table 1. In Taiwan, there is no limit on the concentration of GA and AA used in cosmetic products. ART, however, can be used up to 7 wt.% and MAP up to 3 wt.%. Although there is no limit on the concentration of GA used in cosmetic products, it was reported by US Food and Drug Administration that this whitening agent can cause severe burns or swelling of the skin [9]. In general, about 30-40 wt.% of GA is used in the cosmetics to be used in the beauty salons and a higher concentration, 50-70 wt.%, is used in the cosmetic products to be used by physicians [10].
The purpose of this study is to develop a quantitative analysis method to accurately measure the level of the whitening agents in cosmetic products. This work is of great importance for public safety. Although there are many publications describing the estimation of the whiteners in cosmetic formulations [11-16], the simultaneously quantitative analysis methods have not yet been reported in the literature. This study is related to an analytical method, which can detect and simultaneously quantify the hydrophilic whitening agents.
The hydrophilic whitening agents are not always stable in an aqueous solution. They are subjected to oxidation. Although several studies for the stability of AA had been reported [17-19], the environment of AA in these reports is not suitable for the HPLC for the simultaneous determination of the hydrophilic whiteners. It is important to make sure that the hydrophilic whitening agents are stable during the analysis for the accuracy of the results.
2. Experimental
2.1. Reagents and standards
GA, AA, ART, and MAP and the commercial were purchased from Alfa Co. (American), Alfa Co. (American), Wako (Japanese), and Lipo. Co. (American), respectively. Methylparaben and U-13 are obtained from Induchem. Co. (Switzerland). Citric acid, tetrabutylammonium hydroxide (TBAH), sorbitol, phosphoric acid, and potassium dihyrophosphate were purchased from Aldrich Co. (American). All chemicals were of analyticalreagent grade. Commercial cosmetic products, from various manufacturers, were purchased from retail stores and from a local pharmacy. Solvents and water were filtered through a 0.45 mm membrane and degassed.
2.2. Instrumentation
The HPLC apparatus (Hitachi Co., Japan) consisted of a modular chromatographic system. To which a pump (Model I-7100), a UV detector (Model I-7420; variable wavelength), and an injection valve with a 25 ml sample loop (Model 7725, Rheodyne, Cotati, US) was attached. Data acquisition and processing were accomplished with a personal computer using SISC software (Taiwan). Sample injections were effected with a syringe of 25 ml (Hamilton, Switzerland). A 5 mm, 250 mm/ 4.60 mm I.D. A Stainless-steel Mightysil RP-18GP column was used.
2.3. Chromatographic conditions
Chromatographic analysis was carried out with a single column isocratic reverse phase method. In the ion-pairing method, the mobile phase was a 0.005 M potassium dihydro phosphate buffer solution including three chemicals: TBAH, methanol, and phosphoric acid. The amount of these three chemicals have a great effect on the separation and the resolution of the spectrum of the HPLC. The concentration of TBAH was varied from 1 to 10 mM; methanol from 1 to 10 vol.%. A varied amount of phosphoric acid was added to the buffer solution to adjust the pH values from 2.5 to 5.0. The testing results will allow a suitable mobile phase to be chosen for a good resolution. All mobile phases were filtered through a Millipore filter, pore size 0.45 mm, and degassed by sonication before being used. A flow rate of 1.1 ml/min was used. The analytes were detected by UV absorption at 220 or at 240 nm. The identity of the four ingredients was assigned by chromatography with authentic standards. Quantification was carried out by the integration of the peak using the external standardization method.
cistanche benefits of whitening effective skin
2.4. Calibration curve
Stock solutions were prepared by accurately weighting the agents and then dissolving them in water. Five working solutions of the four analytes were freshly prepared from their stock solutions by a ratio of 1-10 with distilled water. Appropriate dilution of these working solutions gave concentrations of 10/300 mg/ml, except for GA and MAP, where the concentrations were 8.0-36.0 mg/ml and 5.6/451 mg/ml, respectively. Calibration curves were constructed by plotting the peak areas of each component versus concentration and gave the values of the slope, along with the intercept and correlation coefficient for each calibration curve. The calibration curves were for the quantification of the four whitening agents in four samples of commercial cosmetics.
2.5. Recovery study
A sample cream containing no whitening agents was used as a control in the recovery study. The varied amount of the four hydrophilic whitening agents, GA, AA, ART, and MAP, was added to this control cream. The concentration was given in Table 4. About 1 g of each of the prepared sample cream was weighed into a glass flask and 30 ml of distilled water was added and then the flask was immersed in an ultrasonic bath for 15 min thermostatted at 25 8C. The resulting solution was made up to a volume of 100 ml with distilled water and then was filtered and deoxygenated by N2 for about 3 min and then sealed with a Bakelite screw-cap and a silicone ring.
3. Results and discussion
3.1. Chromatography and resolution
The structure of four whitening agents, GA, AA, ART, and MAP, is shown in Table 1. All of them are very polar molecules. For polar analytes, methanol or acetonitrile is usually used as a component of the mobile phase in the C18 column or cyano-propyl column of HPLC. However, the co-elution of these polar analytes was found when methanol or acetonitrile was used. Therefore, it is impossible to separate these analytes. To solve this problem of the co-elution, the ion-pairing method was employed for reducing their polar character to obtain an accepted retention time. In addition, it is important to find a suitable separation condition for the simultaneous analysis of four analytes in cosmetic products. In order to obtain the optimum analytical condition, the influence of the mobile phase and its pH values are considered here. The results obtained are illustrated in Fig. 1. The concentration of TBAH in the mobile phase was varied from 1 to 10 mM. The calculated capacity factor decreases as the concentration of the TBAH increases (see Fig. 1(a)). This drop in the values of the capacity factor is sharp for MAP but very mild for GA, ART, and AA. The significant difference for the capacity factor between MAP and the others can be due to the strong ionic character of MAP. A smaller difference in the capacity factor gives a reasonable retention time in HPLC. Therefore, the concentration of TBAH was chosen to be 10 mM for the mobile phase. The effect of the amount of methanol on the capacity factor was shown in Fig. 1(b). Similar results were found to those for TBAH. A higher concentration of methanol, a smaller difference in the capacity factor, and a shorter retention time in HPLC. Ten percent of methanol in volume was chosen in this case.
A varied amount of phosphoric acid was added to the buffer solution mentioned above to alter the pH values from 2.5 to 5.0. At pH value of 5.0, broad and multiple peaks were observed in the chromatograph results. The chromatograph peaks for GA, AA, and ART are overlapped with each other. Unlike the previous results, the capacity factor increases with the increase of the pH values for MAP (see in Fig. 1(c)). The change in the capacity factor due to pH values is very small for GA, AA, and ART. It is essential to choose a pH value that gives enough differences in the values of the capacity factor for a good resolution in the HPLC. For these reasons, a pH value equal to 2.5 was chosen. As a result, a suitable mobile phase for HPLC analysis is a 0.005 M potassium dihydrophosphate buffer solution containing 10 mM TBAH, 10 vol.% of methanol, and phosphoric acid. The phosphoric acid was used to adjust the pH value of the buffer solution to 2.5.
3.2. Determination of wavelength for UV detector
The UV spectrum of these whitening agents dissolved in the mobile phase was obtained by using a UV spectrophotometer. The maximum absorption peak is at 220 nm for GA, at 243 nm for AA, at 227 nm for ART, and at 238 nm for MAP. At 240 nm, the UV detector has a high sensitivity in detecting AA and MAP, but very low sensitivity for GA and ART (see Fig. 2(b)). While at 220 nm, clear peaks in the HPLC chromatograph were shown for all the four whitening agents (see Fig. 2(a)). To obtain a better sensitivity for all of the analytes, the wavelength of the detector was adjusted to 220 nm for the detection and quantification of four analytes. The procedure is relatively rapid with an analytical run time of 12.1 min at room temperature (around 26 8C).
3.3. Stability study for whitening agents
The AA undergoes decomposition to dehydroascorbic acid (DHA) when dissolved in an aqueous. Therefore, it is of importance to keep the ascobic acid stable during analysis for the accuracy of the results. Fernandes et al. reported that the principal factors affecting the degradation are oxygen and temperature [19]. In their study, the degradation was significant in 1 h, and the effect of pH values of the solution on the degradation was only mentioned at pH 5.0 and 5.6. In our study, the stability of AA was assessed utilizing the concentration change of AA in a variety of different environmental conditions such as treated or untreated solution with N2, pH value and temperature. The longer the time for a significant change, the more stable ascorbic is.
The results, summarized in Table 3, demonstrate a strong correlation between stability and treated or untreated solution with N2. The loss of AA in untreated solution is more rapid than the treated solution. As shown in Table 3, at 10 8C and pH 2, the time required for 10% degradation of the AA was about 10 h for no treatment and about 48 h for the treated solution. This may be due to the factor that much less oxygen is available for oxidation. It is noted that, in presence of oxygen and at 25 8C, the level of the AA of 8.7 and 71.2% after 10 h was observed for pH 6.9 and 2.0. This result can be explained by the higher amount of dissociated AA at pH 6.9 and this form should be less stable than the undissociated form [19]. On the contrary, in the absence of oxygen and at 25 or 10 8C, the aqueous solution of AA is much better stable at pH 6.9. The reason for the AA to be more stable has not yet been further investigated. In relation to solution temperature, in untreated solutions, the AA is less stable at a higher temperature (25 8C) than at a lower temperature (10 8C). However, for treated solutions, the aqueous solution of AA is stable and was not affected by the temperature.
3.4. Validation for linearity and assay for precision
Using the chromatographic conditions described, a reasonable resolution was achieved between these analytes and the others compounds in the cosmetic product. The method was validated for linearity and precision. Linear curve fitting was applied to calculate the calibration curves for eachwhitening agent. The results are given in Table 4. Excellent linearity was obtained over the range from 5.6 to 451 mg/ml for all standards except for GA for which the range was from 8 to 36 mg/ml. The correlation coefficient is ranged from 0.9974 to 0.9997. The precision of the method was calculated as the relative standard deviation (R.S.D., n=5) of assays containing the four hydrophilic whiteners in the same range of concentration. The R.S.D. range was found to be from 0.3 to 6.43%.
3.5. Recovery
A cream containing no whitening agents was used as a control in the recovery study. Small amounts of the four whitening agents were added to this control cream. The HPLC chromatography shows that there is no UV absorption peak detected for a control cream (see Fig. 3(a)) and four absorption peaks were found for a sample cream containing these four whitening agents. In Fig. 3(b), peak 1 is the UV absorption peak for GA; peak 2 for AA; peak 3 for ART; peak 4 for MAP. Each whitening agent has its own retention time. This character will be used to identify these whitening agents later on. The results are summarized in Table 2. A range of 94-100% recovery for the four agents was obtained at both low and high concentrations. The coefficients of variance calculated from three replicates were all less than 6.9%. The HPLC chromatograms of four analytes extracted from the experimental formulation were shown in Fig. 3 and no interference was observed.
cistanche plant has anti-aging, antioxidant, and skincare effects
3.6. Application
Four commercially available cosmetic products were analyzed. They are whitening cream (cosmetic number 1), C20 whitening gel (cosmetic number 2), essence lotion (cosmetic number 3), and peel lotion (cosmetic number 4), respectively. These cosmetics were assayed using the procedure described in this study. The chromatographs for these four cosmetics are given in Fig. 4(a/d). Chromatograph 4 (a) gives a small absorption peak of peak 4, i.e. cosmetic number 1 contains MAP. Chromatograph 4 (b) exhibits a peak of peak 2, which is an indication that cosmetic number 2 contains AA. From chromatograph 4 (c) and (d), ART was identified in cosmetic number 3 and both GA and AA were identified in cosmetic number 4. There is an unmarked peak in chromatograph 4 (d). This UV absorption peak has a retention time longer than for peak 3 but much shorter than for peak 4. It is clear that this unmarked absorption peak is not due to the whitening agents but due to other ingredients in cosmetic number 4. Quantification of these whitening agents was carried out by the integration of the peaks in the chromatography using the external standardization method. The level of the whitening agents in these four cosmetics is given in Table 5. It is noted that the results obtained confirm the accuracy and show compliance with the labeled claim.
4. Conclusion
The HPLC assay developed is simple and rapid for the simultaneous analysis of the hydrophilic whitening agents. A capacity factor was used to choose a suitable mobile phase for HPLC. We need to choose a condition that gives a smaller difference in the capacity factor for a reasonable retention time. It is essential for the chosen condition to give enough differences in the values of the capacity factor for a good resolution in the chromatograph of HPLC. As a result, a suitable mobile phase for HPLC analysis is a 0.005 M potassium dihydrophosphate buffer solution containing 10 mM TBAH, 10 vol.% of methanol, and phosphoric acid. The phosphoric acid was used to adjust the pH value of the buffer solution to 2.5. A better detection wavelength for the whitening agents is at 220 nm for the HPLC. In addition, a convenient method for stabilizing AA in the analytical procedure has been obtained. Which is important for the accuracy of the results.
