Central Fbrous Areas: Changes in Glomerular Vascular Pole Lesions Associated With Age And Disease

Abstract

1. Purpose

Central fibrous areas (CFAs) are small, hyalinotic, monotonous nodular areas observed in glomerular vascular pole lesions. We attempted to clarify the relationship between CFA formation and age in healthy kidneys and in those affected by immunoglobulin A (IgA) nephropathy.

2. Methods

Zero-hour biopsy specimens from living renal donors (135 cases) and IgA nephropathy biopsy specimens (67 cases) were collected retrospectively. We observed each biopsy specimen and determined the total number of glomeruli, the total level of glomerulosclerosis, the number of observable glomerular vascular poles, the number of glomeruli with CFAs, serum creatinine level, and estimated glomerular filtration rate (eGFR). Additionally, we calculated the glomerular sclerosis rate (GSR), vascular pole appearance rate (PAR), and CFA rate (CFAR) to evaluate the relationship between these factors and patient age.

3. Results

There was a significant negative correlation between patient age and eGFR for both the zero-hour (p<0.0001 in Spearman, p=0.0009 in multiple regression, the same hereafter) and IgA (p=0.0022, p=0.0001) groups. In the zero-hour group, we observed a significant positive correlation between patient age and GSR (p=0.0001, p<0.0001); however, there was no such correlation in the IgA group. In both groups, there was a significant positive correlation between patient age and CFAR (zero-hour group: p=0.0003, p=0.0091, IgA group; p<0.0001, p=0.0004). The slope of the regression line of the IgA group formula was also significantly higher than that of the zero-hour group formula (p<0.01).

4. Conclusion

These findings indicate that CFA may be a useful indicator of kidney aging, especially in patients with kidney disease caused by IgA nephropathy.

5. Keywords

Central fibrous area · Aging · Renal donor · IgA nephropathy

Click here to know what is the effect of Cistanche

Introduction

Changes to the vascular poles of the renal glomeruli have been reported much less frequently than changes to other parts of the glomeruli, such as mesangial lesions [1] and those affecting podocytes [2–4] and the glomerular basement membrane [1, 3, 5, 6]. However, small hyalinotic nodular areas have sometimes been observed in glomerular vascular pole lesions. These nodules are monotonous and are stained blue by Masson staining, are weakly positive for periodic acid Schif (PAS) staining, and can be immunohistochemically positive for immunoglobulin M (IgM) (Fig. 1).

Fig. 1 Light microscopic findings of central fibrous areas (CFA) I the same glomeruli (a–c) and immunoglobulin M (IgM) immunohistochemical staining of another glomerulus (d). Small monotonous hyalinotic nodule in a glomerular vascular pole lesion (arrow). The nodule was stained blue by Masson staining (a) and exhibited weakly positive periodic acid Schif (PAS) staining (d), negative or weakly positive periodic acid silver-methenamine (PAM) staining (c), and immunohistochemically positive IgM staining (arrow) (d)

Few reports have described these nodules. Our search identified only one report by Inomata [7] published in 1986, in which the author referred to the lesions as vascular pole deposits (VPD). However, we have observed these nodules in renal histopathological specimens at some frequency. Therefore, we believe that the nodules form as a result of some significant effects on the kidney tissue. In the present study, we defined nodules as central fibrous areas (CFAs).

To date, no statistical evidence for the association between CFA formation and patient age has been reported. Therefore, in this study, we attempted to clarify the relationship between CFA formation and aging using renal biopsy specimens. We also attempted to evaluate the influence of glomerular disease (represented by immunoglobulin A (IgA) nephropathy) on CFA formation. Given that we have observed that CFAs are common in the kidney tissue of older patients, we hypothesized that renal tissue aging promotes CFA formation.

Materials and methods

Living renal donors from the Department of Urology of Tokyo Women’s Medical University and patients with IgA nephropathy who underwent their first renal biopsy at the Department of Nephrology or Department of Pediatric Nephrology of the same university were biopsied between January 2014 and June 2015. All donors underwent a zero-hour biopsy during donor nephrectomy. All donors and patients with IgA nephropathy with diabetes and/or a glomerular disease other than IgA nephropathy were excluded to eliminate external factors that could affect kidney structure to the greatest extent possible. Patients who were prescribed antihypertensive agents were included if their blood pressure was successfully controlled.

The participants were divided into two groups as follows: the zero-hour group, which consisted of donors without IgA nephropathy, and the IgA group, which included patients with IgA nephropathy. Donors diagnosed with IgA nephropathy when a zero-hour biopsy was performed were also classified into the IgA group.

Information regarding age, sex, serum creatinine (sCr), and estimated glomerular filtration rate (eGFR) was reviewed retrospectively from the patient’s medical records just before their donor operation or renal biopsy. We used eGFR data from patients who were≥18 years old when the renal biopsy was performed because the eGFR calculation formula for children younger than 18 years differed from that for adults, and eGFR had not been calculated for most of the child patients.

Standardized Cistanche

Pathological examinations

We used the prepared specimens from stocks that had previously been clinically diagnosed. Donor zero-hour biopsy specimens were collected via wedge biopsy. Renal biopsy specimens from the Department of Nephrology or the Department of Pediatric Nephrology were collected via needle biopsy.

Biopsy samples were fixed in 10% buffered formaldehyde and embedded in paraffin blocks. The samples were sliced into 2-μm thick sections and stained with hematoxylin–eosin (HE), Masson, Elastica-Masson, PAS, and periodic acid silver-methenamine (PAM)-HE. These specimens were observed using a light microscope to examine the number of total glomeruli, the total level of glomerulosclerosis, the presence of glomeruli with an observable vascular pole, and the presence of glomeruli with a CFA in their vascular pole lesion. We determined that a CFA was present when a monotonous nodular lesion was observed in two serial sections of the same glomerulus.

sclerosis rate (GSR) was the rate of glomerulosclerosis to the total number of glomeruli. CFAs are histopathological findings that can be recognized only in glomeruli with an observable vascular pole. For this reason, the number of glomeruli with an observable vascular pole lesion in each specimen should be the denominator for the numerical evaluation of CFA appearance. We calculated the rates of glomeruli with an observable vascular pole to non-sclerotic glomeruli, then nominated the result as the vascular pole appearance rate (PAR). Then, we calculated rates of glomeruli with CFA to glomeruli with an observable vascular pole lesion in each specimen and nominated the result as the CFA rate (CFAR).

The formulas for GSR, PAR, and CFAR are as follows: GSR=glomerulosclerosis number/total glomerular number, PAR=number of glomeruli with an observable vascular pole/(total glomeruli – total with glomerulosclerosis), and the CFAR=number of glomeruli with CFA/number of glomeruli with an observable vascular pole.

Statistical analysis

We calculated the key statistics of each clinical and histopathological parameter for the zero-hour and IgA groups. Continuous variables were expressed as the mean standard deviation (SD). To compare data between the zero-hour and IgA groups, we used two-tailed Mann–Whitney U-tests except for the male/female ratio, for which the 2 ×2 chi-square test was used.

Spearman’s rank correlation coefficients (two-tailed) and multiple regression analysis were used to evaluate the relationships between patient age and the sCr, eGFR, GSR, and CFAR in each group. However, for the eGFR evaluation, we only used data from patients aged≥18 years for the 135 zero-hour cases and 58 IgA cases. In addition, we evaluated the difference between the zero-hour and IgA groups’ regression curves using covariate analysis.

Statistical significance was set at p <0.05. Statistical analyses were performed using Microsoft Excel version 16 (Microsoft Corporation, USA).

Ethical considerations

The study was performed by the 2013 Declaration of Helsinki. Written comprehensive permission was obtained from the patients or the parents of minor patients before the donor operation or renal biopsy. Informed consent was obtained in the form of opt-outs on the website of Tokyo Women’s Medical University. The medical ethics committee of Tokyo Women’s Medical University approved this study protocol (approval no. 3802-R2).

Herba Cistanche

Discussion

This is the first study to quantitatively measure CFAs using renal biopsy specimens. We aimed to verify the hypothesis that renal tissue aging promotes CFA formation. To achieve this aim, we quantitatively measured CFARs in each renal biopsy specimen and statistically evaluated the relationship between patient age and CFAR. The results of the study revealed that older kidney tissue exhibited CFAs more frequently than younger kidney tissue in both the zero-hour and IgA groups. Furthermore, CFAR increased with age more prominently in the IgA group than in the zero-hour group.

Structural and functional changes in kidney tissue related to healthy aging have been observed in various ways. GFR gradually decreases during healthy aging [3, 5, 6, 8]. Studies of relatively healthy people have reported that GFR decreases by 0.4–0.75 ml/min/1.73 m2 /year [5, 8], or by 6.3–10 ml/min/1.73 m2 /decade [1, 3]. We also observed that older donors exhibited lower eGFR (decreased by approximately 0.45 ml/min/year), reflective of the healthy aging process.

Some reports support the notion that the glomerular volume increases with healthy aging [1, 2, 4, 9], but other studies have yielded contrasting results [3, 8]. Changes in nephron structure occur during aging [1–3, 8], and aged kidneys appear to exhibit tubule enlargement [3, 8]. The average percentage of connective tissue in non-sclerosed glomeruli increases during aging [1], and podocytes also undergo age-related changes [2, 3]. Researchers have hypothesized that the progressive reduction of viable and normally functioning podocytes leads to glomerular obsolescence and deterioration of the integrity of the slit pore membrane in glomeruli [3]. Hodgin et al. observed that the total glomerular volume and glomerular volume per podocyte increase with age [2]. In addition, some specific podocyte stress and podocytopathy are observed more frequently in aged kidneys. These findings indicate that podocytopathy may be a significant indicator of kidney aging. However, the relationship between the severity of podocytopathy and renal disease remains unclear.

Few studies have evaluated age-related changes in glomerular vascular pole lesions. In 1986, Inomata investigated kidney biopsy specimens and observed globular hyaline deposits around the glomerular vascular pole, referring to these lesions as VPDs [7].

Inomata formed two hypotheses regarding VPD generation. One hypothesis is that plasma proteinaceous materials penetrate the vascular intima of the glomerular vascular pole lesion and stabilize the local vascular wall. The other is that mesangial deposits in the glomeruli move to the vascular pole lesion via the mesangial channel and accumulate there. However, the author reported no correlation between VPD formation and immune reactions. Indeed, the entire biopsy specimen investigated exhibited some form of renal disease, so the VPDs may have been affected by renal diseases.

In this study, we observed that CFAs were more frequent and larger in older kidneys than in younger kidneys (Fig. 6). Based on these observations, we hypothesized that CFAs develop during aging. Therefore, we investigated the relationship between CFAs and kidney age using renal transplant donor tissues. Unfortunately, we did not measure the size of the CFAs in this study, although we believe that this is an important parameter that should be investigated in future studies.

For zero-hour donor's kidneys, we observed a significant positive correlation between age and GSR; however, for IgA nephropathy kidneys, we observed no significant correlation between patient age and GSR. It is possible that glomerulosclerosis due to IgA nephropathy caused variations in the patients’ GSR, which may have appeared to be a change due to aging. However, we found that for older patients, the CFAR was significantly higher in both the zero-hour and IgA groups. In contrast to the zero-hour group, we observed a positive relationship between patient age and CFAR in the IgA group, and the CFAR of the IgA group exhibited a significantly more rapid increase according to age than the CFAR of the zero-hour group.

Cistanche capsules

The mechanism of CFA formation has rarely been investigated. However, it is known that glomerular capillaries, including vascular pole lesions, are exposed to various types of pressure and movement over time. Glomeruli withstand vascular hydrostatic pressure (60–65 mmHg), plasma colloid osmotic pressure (25 mmHg at the afferent end and up to 35 mmHg at the efferent end), and urinary space hydrostatic pressure (20–25 mmHg) [10]. We presume that persistently high pressure impacting glomerular vascular pole lesions plays a role in CFA formation.

Neal et al. investigated the three-dimensional structure of adult human glomerular capillaries [10]. They found that glomerular vessels at vascular pole lesions expand to a greater extent than connecting arteries, which are called afferent and efferent vascular chambers (VCs). These VC structures have not been observed in either rodent or infant kidneys, in which glomeruli are smaller than adult human glomeruli, which suggests that VCs are associated with large adult glomeruli. These authors simulated hemodynamics in the glomeruli and hypothesized that VCs play a role in ensuring uniform blood distribution to each of the glomerular lobules.

As we observed, a CFA is a structural change that occurs in the VC wall, potentially due to the degradation of VC wall components from being exposed to a high-pressure environment for decades, resulting in CFA formation in aged glomeruli. IgA nephropathy is a form of glomerulonephritis with IgA-dominant immunocomplex deposition in the glomerular mesangial and para mesangial lesions. Many IgA nephropathy kidney tissues exhibit proliferative endocapillary changes, crescent formation, and tubulointerstitial damage, in addition to mesangial matrix expansion and mesangial cell proliferation. These structural changes in glomeruli may disturb glomerular blood flow in patients with IgA nephropathy. However, no studies have discussed actual glomerular blood flow in the context of IgA nephropathy. Future studies should examine the relationships among glomerular structure, glomerular blood flow, IgA nephropathy, and CFA formation.

Therefore, it remains to be determined whether IgA nephropathy is associated with renal aging. The Oxford classification of IgA nephropathy is widely used as a histopathological indicator to predict the clinical outcomes of patients with IgA nephropathy [11]. The classification includes histopathological criteria, interstitial fibrosis/tubular atrophy, and arteriosclerosis, and these criteria are also recognized as aging-related changes. Research has demonstrated that patients with IgA nephropathy who are estimated to have more aging-related changes exhibit poorer clinical outcomes, such as older age [12, 13], higher serum creatinine levels, interstitial fibrosis, and tubular atrophy [13].

Kidney tissue with IgA nephropathy may promote age-related or aging-like changes. For example, klotho is a transmembrane protein that acts as a coreceptor for the major phosphating, fibroblast growth factor-23 (FGF23), which is regarded as an anti-aging protein [5, 14, 15]. Klotho has various roles in ameliorating vascular calcification, tissue hypoxia, and kidney fibrosis [5, 14]. One study involving a cohort of healthy people aged 70–79 years divided the participants according to their soluble klotho levels, reporting that higher klotho levels were associated with lower odds of relative decreases in kidney function [14]. In contrast, klotho expression in renal tissue affected by IgA nephropathy decreased as its histopathological severity progressed [15]. Indeed, we do not have a clear answer regarding the relationship between IgA nephropathy and tissue aging.

Cistanche tubulosa

Conclusion

The present study demonstrated that aging is an independent factor that promotes CFA formation. In both the zero-hour and IgA groups, biopsy specimens from older patients exhibited significantly higher CFARs, and the IgA group exhibited greater increases in CFAR with age than the zero-hour group. On the other hand, GSR was the most significant aging marker in the zero-hour group; however, there was no relationship between GSR and patient age in the IgA group. These findings indicate that CFA may be a useful indicator of kidney aging, especially in kidneys affected by IgA nephropathy. Nonetheless, further investigation is required to clarify its usefulness.

References

1. Stojanovic VR, Janovic ID, Ugrenovic SZ, Vasovic LP, Zivkovic VS, Jocic MV, Kundalik BK, Pavlovic MN (2012) Morphometric analysis of non-sclerosed glomeruli size and connective tissue content during the aging process. Sci World J 2012:845046. https:// doi.org/10.1100/2012/845046

2. Hodgin JB, Bitzer M, Wockman L, Afshinnia F, Wang SQ, Conner CO, Yang Y, Meadowbrooke C, Chowdhury M, Kikuchi M, Wiggins JE, Wiggins RC (2015) Glomerular aging and focal global glomerulosclerosis: a photometric perspective. J Am Soc Nephrol 26:3162–3178. https://doi.org/10.1681/ASN.2014080752

3. Denic A, Glassock RJ, Rule AD (2016) Structural and functional changes with the aging kidney. Adv Chronic Kidney Dis 23:19– 28. https://doi.org/10.1053/j.ackd.2015.08.004

4. Puelles VG, Douglas-Denton RN, Cullen-McEwen LA, Li J, Hughson MD, Hoy WE, Kerr PG, Bertram JF (2015) Podocyte number in children and adults: associations with glomerular size and numbers of other glomerular resident cells. J Am Soc Nephrol 26:2277–2288. https://doi.org/10.1681/ASN.2014070641

5. O’Sullivan ED, Hughes J, Ferenbach DA (2017) Renal aging: causes and consequences. J Am Soc Nephrol 28:407–420. https:// doi.org/10.1681/ASN.2015121308

6. Glassock RJ, Rule AD (2012) The implications of anatomical and functional changes of the aging kidney: with an emphasis on the glomeruli. Kidney Int 82:270–277. https://doi.org/10.1038/ki. 2012.65

7. Inomata I (1986) A clinicopathological study on vascular pole deposits observed in renal biopsy specimens. Jikeikai Med J 101:1009–1020 ((in Japanese))

8. Hommos MS, Glassock RJ, Rule AD (2017) Structural and functional changes in human kidneys with healthy aging. J Am Soc Nephrol 28:2838–2844. https://doi.org/10.1681/ASN.2015121308

9. Tan JC, Workeneh B, Busque S, Blouch K, Derby G, Myers BD (2009) Glomerular function, structure, and number in renal allografts from older deceased donors. J Am Soc Nephrol 20:181– 188. https://doi.org/10.1681/ASN.2008030306

10. Neal CE, Arkill KP, Bell JS, Betteridge KB, Bates DO, Winlove CP, Salmon AHJ, Harper SJ (2018) Novel hemodynamic structures in the human glomerulus. Am J Physiol Renal Physiol 315:F1370–F1384. https://doi.org/10.1152/ajprenal.00566.2017

11. Roberts ISD, Cook HT, Troyanov S, Alpers CE, Amore A, Barratt J, Berthoud F, Bonsib S, Bruijn JA, Cattran DC, Rosanna Coppo R, D’Agati V, et al (2009) The Oxford classification of IgA nephropathy: pathology definitions, correlations, and reproducibility. Kidney Int 76:546–556. https://doi.org/10.1038/ki.2009. 168

12. Duan Z, Cai G, Chen Y, Liang S, Liu S, Wu J, Qiu Q, Lin S, Zhang X, Chen X (2013) Aging promotes progression of IgA nephropathy: a systematic review and meta-analysis. Am J Nephrol 38:241–252. https://doi.org/10.1159/000354646

13. Sevillano AM, Diaz M, Caravaca-Fontàn F, Barrios C, Bernis C, Cabrera J, Calviño J, Castillo L, Cobelo C, Delgado-Malleñ P, Espinosa M, Fernandez-Juarez G, et al (2019) IgA nephropathy in elderly patients. Clin J Am Soc Nephrol 14:1183–1192. https:// doi.org/10.2215/CJN.13251118

14. Drew DA, Katz R, Kritchevsky S, Ix J, Shlipak M, Gutiérrez OM, Newman A, Hoofnagle A, Fried L, Semba RD, Sarnak M (2017) Association between soluble klotho and change in kidney function: the health aging and body composition study. J Am Soc Nephrol 28:1859–1866. https://doi.org/10.1681/ASN.2016080828

15. Yamada K, Doi S, Nakashima A, Kawaoka K, Ueno T, Doi T, Yokoyama Y, Arihiro K, Kohno N, Masaki T (2015) Expression of age-related factors during the development of renal damage in patients with IgA nephropathy. Clin Exp Nephrol 19:830–837. https://doi.org/10.1007/s10157-014-1070-2

Yukiko Kanetsuna1 · Kazunari Tanabe2 · Motoshi Hattori3 · Kosaku Nitta4 · Takahito Moriyama4 · Shigeru Horita5 · Yutaka Yamaguchi6

1 Department of Pathology, International University of Health and Welfare, Atami Hospital, 13-1 higashi-kagan-cho, Atami, Shizuoka 413-0012, Japan

2 Department of Urology, Tokyo Women’s Medical University, 8-1 Kawada-cho Shinjuku-ku, Tokyo 162-8666, Japan

3 Department of Pediatric Nephrology, Tokyo Women’s Medical University, 8-1 Kawada-cho Shinjuku-ku, Tokyo 162-8666, Japan

4 Department of Nephrology, Tokyo Women’s Medical University, 8-1 Kawada-cho Shinjuku-ku, Tokyo 162-8666, Japan

5 Kidney Center, Tokyo Women’s Medical University, 8-1 Kawada-cho Shinjuku-ku, Tokyo 162-8666, Japan

6 Yamaguchi’s Pathological Laboratory, 1-31-20 Minoridai Matsudo-shi, Chiba 270-2231, Japan
