Phosphate Restriction Using A Processed Clay Mineral Reduces Vascular Pathologies And Microalbuminuria in Rats With Chronic Renal Failure

Abstract

1. Background

The progression of chronic kidney disease (CKD) is associated with an increased risk of cardiovascular morbidity and mortality due to elevated serum phosphate levels. Besides low phosphate diets and hemodialysis, oral phosphate binders are prescribed to treat hyperphosphatemia in CKD patients. This study reports on a processed clay mineral as a novel and efficient phosphate sorbent with comparable efficacy to a clinically approved phosphate binder.

2. Methods

5/6 nephrectomized rats, which develop chronic renal failure (CRF), received a high phosphate and calcium diet supplemented with either a processed Montmorillonite-Illite clay mineral (pClM) or lanthanum carbonate (LaC) for 12 weeks. Levels of plasma uremic toxins, glomerular filtration rates, and microalbuminuria were determined and the histomorphology of blood vessels and smooth muscle cells were analyzed.

3. Results

5/6 nephrectomy induced an increase in plasma uremic toxins levels and progressive proteinuria. Treatment of CRF rats with pClM decreased observed vascular pathologies such as vascular fibrosis, especially in coronary vessels. The transition of vascular smooth muscle cells from a contractile to a secretory phenotype was delayed. Moreover, palm administration resulted in decreased blood creatinine and urea levels increased glomerular filtration rates, reduced microalbuminuria, and eventually the mortality rate in CRF rats.

4. Conclusion

Our study reveals pClM as a potent phosphate-binding agent with beneficial impacts on pathophysiological processes in an animal model of CKD. palm effectively attenuates the progression of vascular damage and loss of renal function which are the most severe consequences of chronic renal failure.

Keywords

Chronic Kidney Disease, Chronic Renal Failure, Phosphate Binder, Clay Minerals, Montmorillonite-Illite Clay Minerals, 5/6 Nephrectomy, Microalbuminuria.

Click here to know what is the Herba Cistanche

Introduction

Chronic kidney disease (CKD) is defined by the progressive loss of renal function with a severe reduction of the glomerular filtration rate to <60ml/min/1.73 m2 compared to >90ml/min/1.73 m2 in healthy people [1]. Health implications due to CKD are complex, but elevated serum phosphate levels (>5.5mg/dL) represent a major risk factor for the associated increased cardiovascular morbidity and mortality [2, 3]. Hyperphosphatemia raises calcium release from bones and induces an accelerated progressive vascular calcification and hypertrophy of arterial walls, which results in a mortality rate of approximately 50% in terminal CKD patients due to artery and cardiovascular diseases such as left ventricular hypertrophy (LVH), vascular remodeling, and myocardial fibrosis [4, 5]. Elevated uremic toxins such as phosphate and uric acid cause the transition of vascular smooth muscle cells (SMCs) from a contractile phenotype to an extracellular matrix (ECM) secreting phenotype that contributes to fibrotic cardiac remodeling and increased collagen deposition, both strongly associated with cardiorenal syndrome [6–8]. Pronounced microalbuminuria is often correlated with hypertension and is a well-described prognostic marker for future cardiovascular events [9–11].

According to the clinical relevance of phosphate in CKD, dietary control of phosphate uptake is crucial throughout all stages of CKD, beginning from the earliest stages up to dialysis-dependent end-stage renal disease [12]. The average oral ingestion is about 1.4 to 2.0g phosphate per day and 40–60% of ingested phosphate is intestinally absorbed [13]. Because of the inability of intermittent dialysis to provide a continuously sufficient phosphate clearance, a low phosphate diet and the elimination of dietary phosphate by phosphate adsorbers within the gastrointestinal tract are considered to be mandatory [14]. Furthermore, some phosphate binders exert pleiotropic effects as they attenuate oxidative stress and inflammation, and reduce the circulating levels of uremic toxins [15]. Contrarily, although phosphate binders have certain intrinsic advantages, they also cause gastrointestinal side effects. Together with a high pill burden, those disadvantages are the main reason for the need for new low compliance-demanding phosphate binders with fewer side effects [16, 17].

This study proves the efficacy of a processed Montmorillonite-Illite clay mineral as a phosphate binding agent in uremia-exhibiting rats, which received a 5/6 nephrectomy, in comparison to lanthanum carbonate. These processed clay minerals provide a high phosphate binding capacity due to their specific four-layer structure, high ion exchange capacity, and high content of iron oxide [18]. The main target parameters of this study were (i) survival, (ii) reduction of kidney retention parameters, (iii) effects on vascular morphology, (iv) changes in cardiac muscle tissue, (v) effects on glomerular filtration rate, and (vi) on microalbuminuria. This study indicates an efficient elimination of enhanced dietary phosphate, resulting in reduced vascular pathologies and reduced mortality in CRF rats. The exertion of several beneficial effects in the etiopathology of chronic renal failure reveals a processed Montmorillonite-Illite clay mineral as an interesting and valuable candidate for a new phosphate-binding agent.

Cistanche pills

Methods

1. Phosphate adsorbers

Montmorillonite-Illite clay minerals were refined and provided by FIM Biotech GmbH (Berlin, Germany). Technical processing steps were elutriation, fine grinding, and calcination which resulted in processed clay mineral (pClM). Ground lanthanum carbonate (LaC) tablets (Fosrenol® 750mg, Shire Pharmaceuticals, Hampshire, Great Britain) were used as a reference and positive control.

2. Animal experiments

Male Wistar rats, weighing 200 to 220g, received a stepwise 5/6 nephrectomy by removing one kidney and one week later 2/3 of the second kidney to induce chronic renal failure (n =26), or sham surgery (n =8) (Charles River Laboratories, Germany). Rats were allowed free access to rat chow and tap water during routine husbandry in a 12-h dark/light cycle at 21–22 °C. Untreated chronic renal failure (CRF, n =12) and sham-operated rats (sham) received a high phosphate (disodium phosphate 1.2%, d/w) and calcium (1.2%, d/w) diet. Both nephrectomized treatment groups also received a phosphate-rich (disodium phosphate 1.2%, d/w) and calcium-rich (1.2%, d/w) diet in combination with either 2% (d/w) of a processed clay mineral (pClM, n =6) or lanthanum carbonate (LaC, n =8). Samples of urine and feces were collected using metabolism cages for 24h fortnightly. After 12 weeks, rats were weighed and euthanized by an overdose of i.p. injected ketamine-xylazine (100/25mg/ kg BW) followed by retrobulbar blood collection and subsequent transcardial perfusion with PBS. Tissue samples were either drop-fixed in 4% paraformaldehyde or snap-frozen in liquid nitrogen.

All experimental procedures were approved by and conducted by the guidelines of the State Department of Agriculture, Food Security, and Fisheries Mecklenburg-Western Pomerania (Section 6/ Department 600, Protocol Number: TV 7221.3–1.1- 005/13). The study was carried out in compliance with the ARRIVE guidelines. Rats were weighed weekly and health conditions were checked daily about their fur (smooth), eyes (clean and open), and posture (normal). Animals that lost more than 20% of their body weight or showed abnormal behavior and signs of severe pain were excluded from the experiment.

3. Phosphate measurement via ICP‑OES

For the analysis of phosphate in the feces of rats, phosphate was extracted according to the International Organization for Standardization DIN EN 16174 [19]. The total phosphate of solid samples was measured by inductively coupled plasma optical emission spectrometry (ICP-OES).

4. Analytical chemistry and glomerular filtration rate (GFR)

Levels of uremic toxins in blood and urine were quantitatively determined using a wet-chemical colorimetric method (Cobas Mira Plus, Roche, Germany). Blood samples were centrifuged and plasma concentrations of urea, uric acid, and creatinine were determined. Phosphate concentration was determined in serum. The uremic retention solutes urea, uric acid, creatinine, and phosphate were measured in 24 h urine collection samples. The volume of excreted urine was documented for calculation of GFR and 24h phosphate excretion and is shown as such. The GFR, creatinine clearance, and blood urea nitrogen (BUN) clearance were calculated as values per animal according to S. Pestel et al. [20].

Cistanche supplement

5. Histochemistry and immunofluorescence

Parafn-embedded tissues were cut into 4μm thick histological sections using a microtome and subsequently deparaffinized and rehydrated before histochemical staining with hematoxylin and eosin dye (Medite, Burgdorf, Germany), or Masson’s Goldner trichrome (Sigma-Aldrich, Germany) according to the manufacturer's protocol. For immunofluorescence labeling, antigen retrieval was performed after deparaffinization and rehydration in heated trisodium citrate buffer (pH6), followed by incubation in blocking solution (4% BSA, 1x PBS, 0.1% Tween) for 1h. The primary antibody against α-smooth muscle actin (α-SMA, Sigma-Aldrich, Munich, Germany) was incubated overnight and detected with Alexa Fluor® 594 anti-mouse IgG (Life Technologies, Ober-Olm, Germany). Fluorescence intensity and collagen content were imaged using a Nikon Eclipse Ti-E microscope (Nikon GmbH, Düsseldorf, Germany).

6. Quantitative histological analyses

For quantification of α-SMA in aortic arch sections, five α-SMA positive areas were randomly selected and the average intensity was measured. Analyses of vascular fibrosis and ventricular hypertrophy from cross-sectional sections of paraffin-embedded hearts were performed according to the protocol described by Finch et al. with minor modifications [14]. In brief, after Masson’s Goldner trichrome staining (i) medial area to luminal area ratio and (ii) perivascular collagen area to luminal area ratio were determined to quantify the severity of cardiac fibrosis. Histological sections were analyzed using NIS-Elements AR software (Nikon GmbH, Düsseldorf, Germany).

7. Western Blot

Total protein concentrations were determined using a BCA™ protein assay kit (Pierce, part of Thermo Fisher Scientific, Rockford, USA). Proteins of tissue homogenates were separated by SDS-PAGE using 20μg total protein per lane. After blotting, membranes were blocked with 1% BSA and initially incubated overnight with primary antibody against α-SMA (1:1000). Blots were then stripped (24mM glycine, 2% SDS, aqua dest, pH2.0) at 65°C, blocked with 1% BSA, and incubated overnight with primary antibody against GAPDH as a loading control (1:1500, Biomol, Hamburg, Germany). HRP-conjugated secondary antibodies (anti-mouse and anti-rabbit 1:10,000, GE Healthcare, Buckinghamshire, UK) were used as detection antibodies. Target proteins were visualized and quantified by Fusion Capt Advance FX7 detection software (Vilber Lourmat GmbH, Eberhardzell, Germany).

8. Statistical analysis

Data are expressed as box plots with median (min to max). All data were tested for normal distribution using the Kolmogorov-Smirnov normality test and analyzed by one-way ANOVA. P values p <0.05 were considered statistically significant. Levels of significance were determined as follows: *p <0.05, **p <0.01, and ***p <0.001. All statistical calculations were performed using GraphPad Prism 6 (GraphPad Software Inc., San Diego, CA, USA).

Cistanche tubulosa

Discussion

A balanced phosphate metabolism is essential to maintain health and well-being. Hyperphosphatemia due to reduced phosphate excretion during renal failure in chronic kidney disease (CKD) results in several related complications such as increased vascular calcification and, therefore, enhanced cardiovascular risk [21, 22]. The inefficient ability of dialysis to remediate elevated blood phosphate concentrations to physiological levels raises the need to reduce phosphate uptake to a minimum [23, 24]. This is realized by a low-phosphate diet supplemented with phosphate adsorbers.

In this study, we present evidence that a specifically processed Montmorillonite-Illite clay mineral (pClM) efficiently binds phosphate and has increased beneficial effects on cardiovascular risk factors in 5/6 nephrectomized Wistar rats in comparison to lanthanum carbonate (LaC), a clinically used phosphate adsorber. The special four-layer structure and the small particle size as well as their mineralogical and chemical composition facilitate the strong ion-exchange capacity of clay minerals (ClM) [18]. If specifically processed to pCIM, ClM possesses a higher phosphate binding capacity compared to LaC. The inability of aqua regia and microwave digestion to sequester the bound phosphate from pClM suggests strong chemical stability once the binding process is completed. Based on these results, pClM was the only ClM used for further animal experiments in this study.

5/6 nephrectomy in rats resulted in significantly increased plasma phosphate levels whereas both, pClM and LaC, successfully prevented this phenotype. Additionally, we found that the 24h phosphate excretion rate was reduced after 5/6 nephrectomy in rats and even further by treatment with pClM and LaC. This indicates a decreased phosphate uptake by the intestines due to the phosphate-binding properties of the adsorbers during the gastrointestinal passage. Additionally, LaC rats showed increased fecal phosphate excretion compared to CRF rats and interestingly also to pClM rats. This is probably because the binding between phosphate and pClM is extremely stable as demonstrated by the inability of aqua regia to remove more than 5% of the bound phosphate. In contrast, this method almost completely removed the phosphate bound to lanthanum carbonate.

Consequences of hyperphosphatemia are vascular pathologies e.g. the production of ECM which enhances the resistance of blood vessels and subsequently induces hypertension [25–27]. In this study, highly elevated formation of ECM was observed in 5/6 nephrectomized rats compared to sham-operated rats. While in pClM-treated animals the amount of ECM was almost reduced to sham levels, LaC-treated animals still revealed a significantly higher quantity than the sham group. The tunica media thickness of the abdominal aorta exhibited a similar pattern. Interestingly, only treatment with pClM but not LaC was capable to reduce this pathological alteration. Consistent with these results, the relative amount of α-SMA within vascular smooth muscle cells (VSMC) was significantly lower in CRF rats as shown by Western Blot analyses. The loss of α-SMA suggests a phenotypic transition from contractile to secretory cells, as shown by Wang et al. [8, 28]. This is conclusively consistent with increased ECM production as shown for CRF rats. Only pCIM prevented this transition completely whereas LaC showed an incomplete prevention. However, hypertrophy of the whole heart and the left ventricle in particular as well as the increased myocyte size developed after 5/6 nephrectomy were avoided by treatment with pClM or LaC. Tus, pClM effectively attenuates the progression of vascular injury which is the most severe consequence of chronic renal failure.

Various studies revealed pronounced proteinuria as a reliable marker for future cardiovascular events such as stroke in CKD patients [29, 30]. In line with these studies, untreated 5/6 nephrectomy rats displayed microalbuminuria, which was attenuated by pClM treatment. Interestingly, excessive urinary microalbumin concentrations could be observed in those animals (all from the group of untreated CRF rats) that died before the intended sacrifice. Likewise, arterial hypertension could have contributed to both: left ventricular hypertrophy and microalbuminuria. In this study, blood pressure measurements could not be conducted. Nevertheless, the phosphate-rich diet and subsequent vascular pathologies might have contributed to potentially increased blood pressure levels. It should also be pointed out that the demonstration of potent phosphate binding in an animal model of CKD may not directly translate to similarly strong effects in humans. Nevertheless, based on our findings, further examinations are indicated due to the promising results of this study. Te demonstrated higher binding efficacy combined with the improved ability of pClM to reduce several cardiovascular risks compared to the clinically used phosphate adsorber LaC strongly suggests to proceed the investigation of pClM to elucidate its full potential.

Cistanche capsules

Conclusions

In summary, palm and LaC revealed beneficial effects regarding the reduction of phosphate levels in blood and urine, retention parameters, and attenuating the decline of the GFR in CRF rats. However, palm exhibited a stronger potential to counteract the development of cardiovascular pathologies. Remarkably, pClM was able to attenuate the decrease in GFR due to 5/6 nephrectomy, to prevent the transition of contractile VSMCs to cells with a secretory phenotype, and left ventricular hypertrophy. These results, especially the reduced excretion of microalbumin, suggest that the processed Montmorillonite-Illite clay mineral bears the potential as a highly potent phosphate binder to treat CKD-associated cardiovascular diseases, which makes it an intriguing candidate for further investigations.

References

1. Girndt M, Trocchi P, Scheidt-Nave C, Markau S, Stang A. The prevalence of renal failure. results from the German health interview and examination survey for adults, 2008-2011 (DEGS1). Deutsches Arzteblatt Int. 2016;113(6):85–91.

2. Shanahan CM, Crouthamel MH, Kapustin A, Giachelli CM. Arterial calcification in chronic kidney disease: key roles for calcium and phosphate. Circ Res. 2011;109(6):697–711.

3. Couser WG, Remuzzi G, Mendis S, Tonelli M. The contribution of chronic kidney disease to the global burden of major noncommunicable diseases. Kidney Int. 2011;80(12):1258–70.

4. Charriere S, Rognant N, Chiche F, Cremer A, Deray G, et al. Chronic renal insufficiency and cardiovascular disease. Annales de cardiologie et d’angeiologie. 2009;58(1):40–52.

5. Agabiti-Rosei E, Muiesan ML. Left ventricular hypertrophy and heart failure in women. Journal of hypertension. Supplement. 2002;20(2):S34–8.

6. Di Lullo L, House A, Gorini A, Santoboni A, Russo D, et al. Chronic kidney disease and cardiovascular complications. Heart Fail Rev. 2015;20(3):259–72.

7. Negri AL. Vascular calcifications in chronic kidney disease: are there new treatments? Curr Vasc Pharmacol. 2005;3(2):181–4.

8. Rensen SSM, Doevendans PAFM, van Eys GJJM. Regulation and characteristics of vascular smooth muscle cell phenotypic diversity. Netherlands Heart J. 2007;15(3):100–8.

9. Adachi H. Microalbuminuria is independent prognostic information for cardiovascular disease. Atherosclerosis. 2014;237(1):106–7.

10. Devereux RB, Alderman MH. Role of preclinical cardiovascular disease in the evolution from risk factor exposure to development of morbid events. Circulation. 1993;88(4 Pt 1):1444–55.

11. Grandi AM, Santillo R, Bertolini A, Imperiale D, Broggi R, et al. Microalbuminuria as a marker of preclinical diastolic dysfunction in never-treated essential hypertensives. Am J Hypertens. 2001;14(7 Pt 1):644–8.

12. D’Alessandro C, Piccoli GB, Cupisti A. The "phosphorus pyramid": a visual tool for dietary phosphate management in dialysis and CKD patients. BMC Nephrol. 2015;16:9.

13. Hahn K, Kuhlmann MK, Ritz E. Phosphat und Nahrung Nephrologe. 2013;8(1):37–42.

14. Finch JL, Lee DH, Liapis H, Ritter C, Zhang S, et al. Phosphate restriction significantly reduces mortality in uremic rats with established vascular calcification. Kidney Int. 2013;84(6):1145–53.

15. RB de O, Okazaki H, Stinghen AEM, Drueke TB, Massy ZA, et al. Vascular calcification in chronic kidney disease: a review. Jornal brasileiro de Nefrologia. 2013;35(2):147–61.

16. Chan S, Au K, Francis RS, Mudge DW, Johnson DW, et al. Phosphate binders in patients with chronic kidney disease. Aust Prescr. 2017;40(1):10–4.

17. Rizk R. Cost-effectiveness of phosphate binders among patients with chronic kidney disease not yet on dialysis: a long way to go. BMC Nephrol. 2016;17(1):75.

18. Kaufhold S, Dohrmann R. Detachment of colloidal particles from bentonites in water. Appl Clay Sci. 2008;39(1–2):50–9.

19. Blume H-P, editor. Handbuch der Bodenuntersuchung. Terminologie, Verfahrensvorschriften und Datenblätter ; physikalische, chemische, biologische Untersuchungsverfahren. Berlin: gesetzliche Regelwerke, Beuth; 2000.

20. Pestel S, Krzykalla V, Weckesser G. Measurement of glomerular filtration rate in the conscious rat. J Pharmacol Toxicol Methods. 2007;56(3):277–89.

21. Shanahan CM. Mechanisms of vascular calcification in CKD-evidence for premature aging. Nat Rev Nephrol. 2013;9(11):661–70.

22. Lima EG, Hueb W, Gersh BJ, Rezende PC, Garzillo CL, et al. Impact of Chronic Kidney Disease on Long-Term Outcomes in Type 2 Diabetic Patients With Coronary Artery Disease on Surgical, Angioplasty, or Medical Treatment. Ann Thorac Surg. 2016;101(5):1735–44.

23. Hruska KA, Mathew S, Lund R, Qiu P, Pratt R. Hyperphosphatemia of chronic kidney disease. Kidney Int. 2008;74(2):148–57.

24. Ketteler M, Biggar PH. Use of phosphate binders in chronic kidney disease. Curr Opin Nephrol Hypertens. 2013;22(4):413–20.

25. Moe SM, Chen NX. Pathophysiology of vascular calcification in chronic kidney disease. Circ Res. 2004;95(6):560–7. 26. van Varik BJ, Rennenberg RJMW, Reutelingsperger CP, Kroon AA, PW de L, et al. Mechanisms of arterial remodeling: lessons from genetic diseases. Front Genet. 2012;3:290.

27. Stinghen AEM, Pecoits-Filho R. Vascular damage in kidney disease: beyond hypertension. Int J Hypertens. 2011;2011:232683.

28. Wang L, Zhang J, Fu W, Guo D, Jiang J, et al. Association of smooth muscle cell phenotypes with extracellular matrix disorders in thoracic aortic dissection. J Vasc Surg. 2012;56(6):1698–709 1709.e1.

29. Monfared A, Salari A, Mirbolok F, Momeni M, Shafghnia S, et al. Left ventricular hypertrophy and microalbuminuria in patients with essential hypertension. Iran J Kidney Dis. 2013;7(3):192–7.

30. Berrut G, Chameau AM, Bouhanick B, Page JD, Hallab M, et al. Microalbuminuria and left ventricular hypertrophy in essential arterial hypertension. A study in nondiabetic patients. Presse medicale (Paris, France : 1983). 1992;21(27):1275–8.

Jacqueline Hofrichter1,2, Kai Sempert1,4, Claus Kerkhof1,3, Anne Breitrück1,2, Reinhold Wasserkort1,2 and Stefen Mitzner1,2

1. Department of Extracorporeal Therapy Systems, Fraunhofer Institute for Cell Therapy and Immunology, Schillingallee 68, 18057 Rostock, Germany.

2. Rostock University Medical Center, Center for Internal Medicine, Nephrology Section, Schillingallee 35, 18057 Rostock, Germany.

3. Department of Biomedical Sciences, University of Osnabrück, Institute of Health Research and Education, Barbarastraße 22c, 49076 Osnabrück, Germany.

4. Present address: Queensland Brain Institute, University of Queensland, St. Lucia 4071, Australia.
