Enteral Ferric Citrate Absorption Is Dependent On The Iron Transport Protein Ferroportin

Abstract

Ferric citrate is approved as an iron replacement product in patients with non-dialysis chronic kidney disease and iron deficiency anemia. Ferric citrate-delivered iron is enterally absorbed, but the specific mechanisms involved have not been evaluated, including the possibilities of conventional, transcellular ferroportin-mediated absorption and/or citrate-mediated paracellular absorption. Here, we first demonstrate the efficacy of ferric citrate in high hepcidin models, including Tmprss6 knockout mice (characterized by iron-refractory iron deficiency anemia) with and without adenine diet-induced chronic kidney disease. Next, to assess whether or not enteral ferric citrate absorption is dependent on ferroportin, we evaluated the effects of ferric citrate in a tamoxifen-inducible, enterocyte-specific ferroportin knockout murine model (Villin-Cre-ERT2, Fpn flox/flox ). In this model, ferroportin deletion was efficient, as tamoxifen injection induced a 4000-fold decrease in duodenum ferroportin mRNA expression, with undetectable ferroportin protein on a Western blot of duodenal enterocytes, resulting in a severe iron deficiency anemia phenotype. In ferroportin-deficient mice, three weeks of 1% ferric citrate dietary supplementation, a dose that prevented iron deficiency in control mice, did not improve iron status or rescue the iron deficiency anemia phenotype. We repeated the conditional ferroportin knockout experiment in the setting of uremia, using an adenine nephropathy model, where three weeks of 1% ferric citrate dietary supplementation again failed to improve iron status or rescue the iron deficiency anemia phenotype. Thus, our data suggest that enteral ferric citrate absorption is dependent on conventional enterocyte iron transport by ferroportin and that, in these models, significant paracellular absorption does not occur.

Keywords

ferric citrate; ferroportin; hepcidin; iron; anemia; chronic kidney disease.

Click here to know what is the effect of Cistanche on Kidney

Introduction

Auryxia (ferric citrate [FC]; Akebia Therapeutics, Inc., Cambridge, MA) is a novel compound that is approved for clinical use as an enteral phosphate binder in adult chronic kidney disease (CKD) patients on dialysis. In randomized, placebo-controlled trials conducted in non-dialysis-dependent CKD patients, FC significantly decreased serum phosphate concentrations.1,2 In randomized, active-controlled trials conducted in dialysis-dependent CKD patients, FC produced similar reductions in serum phosphate concentrations.3,4

Auryxia is also approved in the US for clinical use as an iron-replacement product in CKD non-dialysis patients with iron-deficiency anemia. In the 4 aforementioned randomized controlled trials, conducted in both non–dialysis-dependent and dialysis-dependent CKD cohorts, FC significantly increased serum transferrin saturation (TSAT).1–4 Thus, FC can function as both an effective enteral phosphate binder and an enteral iron source.

Remarkably, FC corrects an iron deficiency in the setting of CKD, and even end-stage renal disease, as these are states with high hepcidin levels.5–8 Hepcidin is the master iron-regulatory hormone, binding to and inhibiting ferroportin, the only known cellular iron exporter.9 In the setting of high hepcidin levels, the activity of ferroportin—located on the basal surface of enterocytes—is decreased, thus inhibiting dietary and medicinal iron absorption from the gastrointestinal lumen 10.

The mechanisms by which FC overcomes the enteral iron block induced by high hepcidin and low ferroportin levels are unclear. One hypothesis is that the citrate moiety in FC chelates calcium ions, leading to disruption of enterocyte intercellular tight junctions, allowing for paracellular iron absorption that is independent of the hepcidin-ferroportin pathway. An interesting point to note is that citrate compounds have been noted to facilitate paracellular enteral absorption of aluminum,11,12 raising the possibility that iron absorption is enhanced by the same mechanism. To assess whether FC-associated enteral iron absorption occurs via a transcellular, ferroportin-dependent route, versus a paracellular, ferroportin-independent route, we evaluated enteral FC absorption in murine models, with or without CKD, with low or absent enterocyte ferroportin activity.

Cistanche supplement

METHODS

1. Mouse experiments

Experiments were conducted by the University of California, Los Angeles (UCLA) Division of Laboratory Animal Medicine guidelines, and the study protocols were approved by the UCLA Office of Animal Research Oversight. Mice were housed at UCLA, in standard cages with wood-chip bedding that was changed twice weekly. Animal housing rooms were temperature and humidity controlled, with a 12-hour light cycle. We first assessed the effects of FC in transmembrane serine protease 6 (Tmprss6) knockout mice, a model characterized by high hepcidin levels, low ferroportin activity, and resultant iron-refractory iron-deficiency anemia,13 both without and with the addition of adenine diet-induced CKD, which further increases hepcidin levels.14 To completely inhibit enteral ferroportin activity, we next assessed the effects of FC in a tamoxifen-inducible, enterocytespecific ferroportin (FPN) knockout model (Villin-Cre-ERT2, Fpnflox/flox). Finally, we assessed the effects of FC in a Villin-Cre-ERT2, Fpnflox/flox model with adenine diet-induced CKD.

2. Tmprss6 knockout mice

Tmprss6 knockout mice on a C57BL/6 genetic background were kindly provided by Dr. Jodie Babitt (Massachusetts General Hospital). We first assessed the effects of FC in Tmprss6 knockout mice and wild-type (WT) littermates without CKD. Mice aged 4–7 weeks were fed 50 ppm iron diets without adenine (Envigo, Hackensack, NJ), with or without 0.1% FC (Akebia Therapeutics, Inc.), for 3 weeks, and then were euthanized. We next assessed the effects of FC in Tmprss6 knockout mice and WT littermates with CKD. Mice aged 8–12 weeks were fed 50 ppm iron diets with 0.2% adenine (Envigo) to induce CKD,15–17 for 6 weeks. For the last 3 weeks of the diets, 0.1% FC (Akebia Therapeutics, Inc.) was added for one group and not added for another. This FC dose in mice corresponds to a typical adult human FC dose; in an adult human, 2 Auryxia tablets taken thrice daily (6000 mg FC) contain a cumulative daily ferric iron dose of 1260 mg, an amount equivalent to approximately one-third of the total body iron. In mice, approximately one-third of total body iron is equivalent to ~0.8 mg of ferric iron daily, or ~4 mg of FC daily which, given murine daily food consumption of ~4 g, corresponds to chow containing 0.1% FC. In these experiments, each group contained approximately half males and half females. After sacrifice, we collected whole blood, serum, liver, and duodenal enterocytes. To isolate duodenal enterocytes, the proximal section of the duodenum (~2 cm) was cut open lengthwise and transferred to ice-cold ethylenediamine tetraacetic acid solution. The solution was vortexed to facilitate cell detachment, and the dispersed cells were collected by filtration.

3. Non-CKD enterocyte-specific ferroportin knockout mice

Tamoxifen-inducible, enterocyte-specific ferroportin (FPN) knockout mice were generated by breeding Villin-Cre-ERT2 mice with Fpnflox/flox mice, both of which are on C57BL/6 genetic backgrounds. Villin-Cre-ERT2 mice were kindly provided by Dr. Peter Tontonoz (UCLA). To characterize this model, we assessed Fpnflox/flox mice, with or without VillinCre-ERT2, with or without tamoxifen induction (0.075 mg/g body weight, injected i.p. once daily for 4 consecutive days; Sigma-Aldrich, St. Louis, MO). To assess the effects of FC in this model, we used Villin-Cre-ERT2, Fpnflox/flox mice aged 6–8 weeks that were i.p. injected with either sunflower oil vehicle (uninduced group) or tamoxifen (0.075 mg/g body weight; induced group) once daily for 4 consecutive days. Mice were maintained on 50 ppm iron diets (Envigo) and then were euthanized 7 weeks post-injection. Some of the tamoxifen-induced mice had 1% FC added to their diets for the 3 weeks immediately before sacrifice. In these experiments, 1% FC—a supraphysiologic dose—was chosen so as not to miss an effect secondary to insufficient FC dosing. To demonstrate the efficacy of this dose, we performed a separate positive control experiment in which we assessed whether 3 weeks of 1% FC dietary supplementation can rescue the iron-deficiency anemia phenotype in uninduced Villin-Cre-ERT2, Fpnflox/flox mice fed a low-iron (4 ppm) diet (Envigo). In the non-CKD enterocyte-specific ferroportin knockout experiments, each group contained both males and females. After sacrifice, we collected whole blood, serum, liver, duodenal enterocytes, and whole duodenum for iron staining. Duodenal enterocytes were isolated as described above. For duodenal iron staining, proximal duodenal samples were fixed in formalin, then embedded in paraffin blocks from which slides were created. Deparaffinized sections were stained with the Perls Prussian blue stain for nonheme iron and counterstained with nuclear fast red. The degree of duodenal enterocyte iron staining was assessed on a semi-quantitative scale by a blinded reviewer (SN).

4. CKD enterocyte-specific ferroportin knockout mice

To repeat the above experiment in the setting of CKD, male Villin-Cre-ERT2, Fpnflox/flox mice aged 6 weeks were started on 0.2% adenine diets (Envigo) to induce CKD. Given gender differences in the adenine diet-induced rodent CKD model (females are more resistant to the effects of dietary adenine),18 only male mice were used. At age 8 weeks, mice were i.p. injected, as described above, with sunflower oil vehicle or tamoxifen. At age 12 weeks, after 6 weeks of the adenine diet, mice were switched to standard, non-adenine, 50 ppm iron diets with or without 1% FC added. Mice were sacrificed at age 15 weeks, 7 weeks post-injection, and after 3 weeks of treatment with or without FC. Whole blood, for hemoglobin and red blood cell measurement, was collected when mice were aged 8 weeks (at the time of injection), 12 weeks (upon initiation of diets with or without FC), and 15 weeks (at sacrifice). Serum, for urea nitrogen and iron measurement, was collected when mice were aged 12 and 15 weeks. Liver and duodenal enterocytes were collected, as described above, at sacrifice.

Herba Cistanche

5. Blood assays

Complete blood counts were measured by the Hemavet 950 automated processor (Drew Scientific, Oxford, CT). Colorimetric methods were used to assay serum urea nitrogen (BioAssay Systems, Hayward, CA) and serum iron (Genzyme, Cambridge, MA). In-house enzyme-linked immunosorbent assays (ELISA) were used to measure serum hepcidin levels, as previously described.19 A commercially available ELISA kit was used to measure serum erythropoietin (R&D Systems, Minneapolis, MN).

6. Quantitative liver iron concentrations

Harvested livers were snap-frozen in liquid nitrogen and stored at −80 °C. Small pieces of the livers (~100 mg) were weighed and homogenized. A protein precipitation solution (0.53 N HCl and 5.3% trichloroacetic acid in double-distilled water) was added, and the samples were boiled and centrifuged. Iron concentrations in the supernatants were measured by a colorimetric assay (Genzyme), then normalized to the weights of the original samples to yield tissue iron concentrations.

7. Quantitative real-time polymerase chain reaction (PCR)

Duodenal enterocytes were homogenized in Trizol (Invitrogen, Waltham, MA), and RNA was isolated according to the manufacturer’s protocol. We performed quantitative reverse transcription (RT)–PCR using the iScript RT-PCR kit (Bio-Rad, Hercules, CA) and primers specific for mouse Fpn (forward: 5’-ATGGGAACTGTGGCCTTCAC-3’; reverse: 5’-TCCAGGCATGAATACGGAGA-3’). We used the following PCR conditions: initial denaturation at 95 °C for 2 minutes, followed by 40 cycles of denaturation at 94 °C for 30 seconds, annealing at 58 °C for 30 seconds, extension at 72 °C for 1 minute, and final extension at 72 °C for 10 minutes. Gene expression was normalized to that of hypoxanthine-guanine phosphoribosyltransferase (Hprt) (forward: 5’-CTGGTTAAGCAGTACAGCCCCAA-3’; reverse: 5’-CAGGAGGTCCTTTTCACCAGC-3’), and each RNA sample was analyzed in duplicate. Relative fold gene expression was calculated using the delta-delta Ct method.

8. Western blotting

For ferritin protein detection on Western blot, the primary antibody used was rabbit anti-mouse FTH1 (D1D4; Cell Signaling Technology, Danvers, MA), at a concentration of 1:10,000, and the secondary antibody used was goat anti-rabbit IgG (Cell Signaling Technology), at a concentration of 1:5000. For ferroportin detection on Western blot, the primary antibody used was rat anti-mouse FPN (1C7; Amgen, Thousand Oaks, CA), at a concentration of 1:3300, and the secondary antibody used was rabbit anti-rat IgG (ab102213; Abcam, Cambridge, MA), at a concentration of 1:5000. For the actin protein loading control, mouse anti-actin antibody (A3854; Sigma-Aldrich), at a concentration of 1:50,000, was used. A chemiluminescent signal was detected using the ChemiDoc XRS+ System with Image Lab software (Bio-Rad).

9. Statistical analysis

Figure creation and statistical analysis were performed using Graph-Pad Prism 9.2.0 (San Diego, CA). Mouse data are presented as means ± SDs, and t-tests were used to compare group means. For non-normally distributed data, log transformation was applied before statistical analysis. P values < 0.05 were considered statistically significant.

Cistanche capsules

DISCUSSION

In clinical studies, FC has been shown to correct iron deficiency in patients with CKD and end-stage renal disease, which are states with high-hepcidin levels.5–8 In the setting of high circulating hepcidin concentrations, enteral ferroportin activity is decreased, engendering a hepcidin-mediated mucosal block to enteral iron absorption.9 The mechanisms by which FC may overcome this enteral absorptive block are unknown. One hypothesis is that the citrate moiety loosens intercellular tight junctions, facilitating paracellular, ferroportin-independent enteral iron absorption. We tested this hypothesis by assessing the effectiveness of FC in high-hepcidin/low-ferroportin models—with and without CKD—in which the transcellular iron absorptive pathway is nearly ablated or completely blocked.

In our first model, Tmprss6 knockout mice without CKD, in which hepcidin levels are mildly elevated, FC improved iron status and increased hemoglobin concentrations. Similarly, in our WT and Tmprss6 knockout models with CKD, in which hepcidin levels are markedly elevated, FC increased red blood cell count and hemoglobin. These data demonstrate the efficacy of FC in states with high hepcidin levels and are consistent with what has been observed in FC clinical studies; however, these models do not suggest what the mechanisms are by which FC overcomes the mucosal hepcidin block.

In these models, in which ferroportin remains intact, FC may be absorbed via a paracellular pathway, bypassing the hepcidin–ferroportin axis, or may be absorbed via a transcellular pathway, utilizing ferroportin. To evaluate the dependence of FC on enteral ferroportin, we used an inducible, enterocyte-specific ferroportin knockout murine model. This model is highly effective at nearly completely depleting enterocyte ferroportin protein, resulting in drastically reduced enteral iron absorption and severe iron-deficiency anemia, a phenotype that can be rescued by parenteral iron administration.26 In this model, any substantial bypass of the canonical ferroportin-dependent pathway would be readily detectable.

In our non-CKD model, in the absence of enterocyte ferroportin, an FC dose that had been effective in WT mice did not improve iron status or rescue the iron-deficiency anemia phenotype. Small increases in red blood cell count and hemoglobin were not statistically significant, suggesting that enteral FC absorption is predominantly dependent on ferroportin, and arguing against extensive paracellular absorption. In the setting of CKD, uremia-associated factors potentially could increase gut permeability,24 possibly loosening intercellular tight junctions and facilitating some degree of paracellular FC absorption. However, in our CKD model, FC significantly improved iron status in the presence of enterocyte ferroportin, but not in its absence. These data suggest that even in the setting of CKD, enteral FC absorption is predominantly mediated by ferroportin transport and not possible paracellular pathways. In the uninduced CKD mice, FC treatment increased duodenum ferroportin protein, despite lower duodenum ferroportin mRNA expression, consistent with an established mechanism by which intracellular iron accumulation triggers IRP-mediated de-repression of ferroportin translation,21–23 thus facilitating cellular iron absorption and delivery to the circulation.

We performed 2 CKD experiments. Terminal average serum urea nitrogen and hemoglobin concentrations were similar between the WT CKD control diet group from the first experiment and the uninduced, untreated CKD group from the second experiment. However, in the first CKD experiment, WT mice treated with FC had a significant increase in hemoglobin, but in the second CKD experiment, the uninduced mice treated with FC did not have a significant increase in hemoglobin. The reason FC did not significantly increase hemoglobin in the uninduced mice, despite clearly improving iron status, is unclear; however, possible contributory factors include the multifactorial etiology of CKD anemia, the small sample sizes of uninduced mice, and the repeated phlebotomy in this experiment. An additional study limitation is that we used mouse models whose translatability to humans is not certain. Also, although robust, the evidence for the lack of significant paracellular absorption of FC is indirect.

Cistanche tubulosa

In summary, in our high-hepcidin-level models, we observed beneficial effects of FC on iron and erythrocytic parameters, suggesting effective enteral iron absorption despite high hepcidin levels. To assess whether FC may bypass the mucosal hepcidin block via potential citrate-facilitated paracellular absorption, we evaluated an inducible, enterocyte-specific ferroportin knockout model, in the presence or absence of impaired kidney function. In these models, FC did not rescue the iron-deficiency anemia phenotype, demonstrating that enteral FC absorption is predominantly dependent on ferroportin, and suggesting that paracellular pathways likely do not constitute major routes of physiologic FC absorption.

REFERENCES

1. Block GA, Fishbane S, Rodriguez M, et al. A 12-week, double-blind, placebo-controlled trial of ferric citrate for the treatment of iron deficiency anemia and reduction of serum phosphate in patients with CKD Stages 3-5. Am J Kidney Dis. 2015;65:728–736. [PubMed: 25468387]

2. Yokoyama K, Hirakata H, Akiba T, et al. Ferric citrate hydrate for the treatment of hyperphosphatemia in nondialysis-dependent CKD. Clin J Am Soc Nephrol. 2014;9:543–552. [PubMed: 24408120]

3. Lewis JB, Sika M, Koury MJ, et al. Ferric citrate controls phosphorus and delivers iron in patients on dialysis. J Am Soc Nephrol. 2015;26:493–503. [PubMed: 25060056]

4. Yokoyama K, Akiba T, Fukagawa M, et al. A randomized trial of JTT-751 versus sevelamer hydrochloride in patients on hemodialysis. Nephrol Dial Transplant. 2014;29:1053–1060. [PubMed: 24376274]

5. Zaritsky J, Young B, Wang HJ, et al. Hepcidin—a potential novel biomarker for iron status in chronic kidney disease. Clin J Am Soc Nephrol. 2009;4:1051–1056. [PubMed: 19406957]

6. Ashby DR, Gale DP, Busbridge M, et al. Plasma hepcidin levels are elevated but responsive to erythropoietin therapy in renal disease. Kidney Int. 2009;75:976–981. [PubMed: 19212416]

7. Zaritsky J, Young B, Gales B, et al. Reduction of serum hepcidin by hemodialysis in pediatric and adult patients. Clin J Am Soc Nephrol. 2010;5:1010–1014. [PubMed: 20299375]

8. Troutt JS, Butterfield AM, Konrad RJ. Hepcidin-25 concentrations are markedly increased in patients with chronic kidney disease and are inversely correlated with estimated glomerular filtration rates. J Clin Lab Anal. 2013;27:504–510. [PubMed: 24218134]

9. Nemeth E, Tuttle MS, Powelson J, et al. Hepcidin regulates cellular iron efflux by binding t ferroportin and inducing its internalization. Science. 2004;306:2090–2093. [PubMed: 15514116]

10. Ganz T, Bino A, Salusky IB. Mechanism of action and clinical attributes of Auryxia ® (ferric citrate). Drugs. 2019;79:957–968. [PubMed: 31134521]

11. Froment DP, Molitoris BA, Buddington B, et al. Site and mechanism of enhanced gastrointestinal absorption of aluminum by citrate. Kidney Int. 1989;36:978–984. [PubMed: 2601265]

12. Gupta A Ferric citrate hydrate as a phosphate binder and risk of aluminum toxicity. Pharmaceuticals (Basel). 2014;7:990–998. [PubMed: 25341358]

13. Folgueras AR, de Lara FM, Pendás AM, et al. Membrane-bound serine protease matriptase-2 (Tmprss6) is an essential regulator of iron homeostasis. Blood. 2008;112:2539–2545. [PubMed: 18523150]

14. Hanudel MR, Rappaport M, Gabayan V, et al. Increased serum hepcidin contributes to the anemia of chronic kidney disease in a murine model. Haematologica. 2017;102:e85–e88. [PubMed: 27884972]

15. Jia T, Olauson H, Lindberg K, et al. A novel model of adenine-induced tubulointerstitial nephropathy in mice. BMC Nephrol. 2013;14:116. [PubMed: 23718816]

16. Tamura M, Aizawa R, Hori M, et al. Progressive renal dysfunction and macrophage infiltration in interstitial fibrosis in an adenine-induced tubulointerstitial nephritis mouse model. Histochem Cell Biol. 2009;131: 483–490. [PubMed: 19159945]

17. Klinkhammer BM, Djudjaj S, Kunter U, et al. Cellular and molecular mechanisms of kidney injury in 2,8-dihydroxyadenine nephropathy. J Am Soc Nephrol. 2020;31:799–816. [PubMed: 32086278]

18. Diwan V, Small D, Kauter K, et al. Gender differences in adenine-induced chronic kidney disease and cardiovascular complications in rats. Am J Physiol Renal Physiol. 2014;307:F1169–F1178. [PubMed: 25209863]

19. Kim A, Fung E, Parikh SG, et al. A mouse model of anemia of inflammation: complex pathogenesis with partial dependence on hepcidin. Blood. 2014;123:1129–1136. [PubMed: 24357728]

20. Finberg KE, Whittlesey RL, Fleming MD, et al. Down-regulation of Bmp/Smad signaling by Tmprss6 is required for the maintenance of systemic iron homeostasis. Blood. 2010;115:3817–3826. [PubMed: 20200349]

21. Darshan D, Wilkins SJ, Frazer DM, et al. Reduced expression of ferroportin-1 mediates the hyporesponsiveness of suckling rats to stimuli that reduce iron absorption. Gastroenterology. 2011;141:300–309. [PubMed: 21570398]

22. Galy B, Ferring-Appel D, Becker C, et al. Iron regulatory proteins control a mucosal block to intestinal iron absorption. Cell Rep. 2013;3:844–857. [PubMed: 23523353]

23. Wilkinson N, Pantopoulos K. The IRP/IRE system in vivo: insights from mouse models. Front Pharmacol. 2014;5:176. [PubMed: 25120486]

24. Meijers B, Farré R, Dejongh S, et al. Intestinal barrier function in chronic kidney disease. Toxins (Basel). 2018;10:298.

25. Schiavi SC, Tang W, Bracken C, et al. Npt2b deletion attenuates hyperphosphatemia associated with CKD. J Am Soc Nephrol. 2012;23:1691–1700. [PubMed: 22859851]

26. Donovan A, Lima CA, Pinkus JL, et al. The iron exporter ferroportin/Slc40a1 is essential for iron homeostasis. Cell Metab. 2005;1:191–200. [PubMed: 16054062]

Mark R. Hanudel1, Brian Czaya2, Shirley Wong2, Maxime Rappaport1, Shweta Namjoshi1, Kristine Chua2, Grace Jung2, Victoria Gabayan2, Bo Qiao2, Elizabeta Nemeth2, Tomas Ganz2

1. Department of Pediatrics, David Geffen School of Medicine at UCLA, Los Angeles, California, USA

2. Department of Medicine, David Geffen School of Medicine at UCLA, Los Angeles, California, USA
